Name: 12-1140V Rated Voltage 0.5-5000KW Rated Power IP54 Protection Permanent Magnet Generator PMG for High Efficiency Applications
Brand: Qingdao Greef New Energy Equipment Co., Ltd
SKU: GDF
Price: 12999.00 USD
Availability: InStock

घर > उत्पादों > स्थायी चुंबक जनरेटर >

12-1140V Rated Voltage 0.5-5000KW Rated Power IP54 Protection Permanent Magnet Generator PMG for High Efficiency Applications

12-1140V Rated Voltage Permanent Magnet Generator

0.5-5000KW Rated Power PMG

IP54 Protection Permanent Magnet Alternator

ब्रांड नाम:

Greef

प्रमाणन:

Model Number:

GDF

हमसे संपर्क करें

उद्धरण मांगें

उत्पाद का विवरण

चुंबक का प्रकार:

एनडीएफईबी

असर ब्रांड:

एसकेएफ

वर्तमान प्रकार:

एसी

ठंडा करने की विधि:

फैन कूलिंग

रेटेड वोल्टाग:

12-1140V

शाफ्ट सामग्री:

इस्पात

मूल्यांकित शक्ति:

0.5-5000KW

संरक्षण जी:

आईपी54

भुगतान और शिपिंग शर्तें

Minimum Order Quantity

1 Set

मूल्य

negotiable

Packaging Details

Foam+plywooden Case

Delivery Time

25 Working Days

Payment Terms

T/T

संबंधित उत्पाद

विडियो

12-1140V Rated Voltage 0.5-5000KW Rated Power IP54 Protection Permanent Magnet Generator PMG for High Efficiency Applications

सबसे अच्छी कीमत पाएं

विडियो

0.5-5000KW Rated Power 12-1140V Permanent Magnet Generator with Long-lasting Copper Stator and PMG Design

सबसे अच्छी कीमत पाएं

विडियो

High Efficiency Permanent Magnet Generator with Max.120℃ Magnet Temperature and Max.180℃ Winding Temperature for Heavy Duty Applications

सबसे अच्छी कीमत पाएं

विडियो

High Efficiency Permanent Magnet Generator with Cast Iron Shell Copper Stator and NdFeB Magnet

सबसे अच्छी कीमत पाएं

हमसे संपर्क करें

अब संपर्क करें

उत्पाद का वर्णन

12-1140V Rated Voltage Three Phase Stator Material Copper for Performance Advanced Hydro PMG Technology

Offering superior voltage regulation capability with advanced Permanent Magnet Generator (PMG) technology.

Product Overview

A Permanent Magnet Generator (PMG) is an advanced type of electric generator that utilizes high-strength permanent magnets on its rotor to create a powerful magnetic field, instead of relying on traditional electrically-excited windings.

Key Advantages

Higher Efficiency: Reduces energy losses, resulting in superior efficiency, especially under partial loads.
Exceptional Reliability: Brushless structure ensures minimal maintenance and a longer operational lifespan.
Compact & Lightweight: Offers a higher power density, making it ideal for space-constrained applications.
Excellent Performance: Provides superior voltage regulation and faster response.

Technical Specifications

Parameter	Value
Rated power	0.5-5000 kW
Rated rotate speed	20-3000 rpm
Rated voltage	48-1140 Vac
Frequency	60/50 Hz
Number of Poles	24
Generator type	3phase AC Synchronous generator
Magnet type	NdFeB
Winding Method	Y
Magnet temperature level	Max.120℃
Winding temperature level	Max.180℃
Efficiency	>95%
Insulate Grade	H

Performance Ratings

Rated Power	Rated Speed	Rated Voltage	Frequency
0.5KW	20rpm~400rpm	12V~220Vac	10Hz~60Hz
1KW	20rpm~600rpm	12V~220Vac	10Hz~60Hz
2KW	20rpm~1000rpm	12V~400Vac	10Hz~60Hz
3KW	20rpm~1500rpm	48V~690Vac	10Hz~60Hz
5KW	20rpm~1500rpm	48V~690Vac	10Hz~60Hz

Applications

Permanent Magnet Generators (PMGs), renowned for their high efficiency, reliability, and compact design, have emerged as the preferred power solution across various modern industrial sectors.

Wind Power Generation: Integral to modern direct-drive and semi-direct-drive wind turbines
New Energy Vehicles: Primary traction motor or auxiliary generator in electric/hybrid vehicles
Marine and Offshore: Ship shaft generators and primary/auxiliary power systems
Backup Power Systems: Diesel and gas generator sets for emergency power
High-Speed Applications: Microturbines and flywheel energy storage systems
Industrial & Military Equipment: Specialized power systems requiring high reliability

Customization Options

Brand Name: Greef

Model Number: GDF

Certification: CE

Minimum Order Quantity: 1 Set

Delivery Time: 25 Working Days

Bearing brand: SKF

Stator Material: Copper

Packaging & Shipping

Our Permanent Magnet Generator is carefully packaged to ensure safe delivery. Each generator is securely wrapped in bubble wrap and placed in a sturdy cardboard box to prevent any damage during transit.

We offer fast and reliable shipping via reputable carriers. Orders are typically processed within 1-2 business days with tracking provided.
